General Specifications
| Gearbox Housing | Ruggedised Die-cast Aluminium |
| Worm Gear Material | Bronze, steel or plastic |
| Lubrication | Grease lubricated & sealed for life |
| Bearing Type | High quality ball bearings |
| Insulation Class | Class F (Optional: Class B) |
| Brush Type | Integral or removable |
| Ambient Operating Temperature | -20℃ to +40℃ |
Performance Data
| Motor Size | Worm Wheel Material | Gear Ratio | Brake Type | Output Shaft |
|---|---|---|---|---|
| 73ZYT,80ZYT,90ZYT | Delrin, Bronze | 12.5:1 | ERB, MRB | Customised |
| 73ZYT,80ZYT,90ZYT | Delrin, Bronze | 25:1 | ERB, MRB | Customised |
| 73ZYT,80ZYT,90ZYT | Delrin, Bronze | 30:1 | ERB, MRB | Customised |
| 73ZYT,80ZYT,90ZYT | Delrin, Bronze | 50:1 | ERB, MRB | Customised |
