General Specifications
| Voltage Range | 12 & 24v dc (220v also available) | |||
| Power Output Range | 200 to 400 watts | |||
| Speed Range | up to 9,000rpm | |||
| Operational Temperature | -20°C to +40°C | |||
| Insulation Class | F(consult us for class B) | |||
| Bear Type | High quality ball bearings | |||
| Housing Type | Closed(ventilated also available) | |||
Performance Data
| Model | Voltage | Rated Power | Rated Speed | Rated Torque | Rated Current | No load Current | No load Speed | Length |
|---|---|---|---|---|---|---|---|---|
| Units | V | W | rpm | mNm | A | rpm | mm | |
| 100ZYT145-12V | 12 | 290 | 3450 | 0.8 | 32.5 | 5 | 3920 | 145 |
| 100ZYT145-24V | 24 | 290 | 3450 | 0.8 | 15.6 | 2.3 | 3920 | 145 |
| 100ZYT165-12V | 12 | 197 | 2350 | 0.8 | 22 | 3 | 2250 | 165 |
| 100ZYT165-24v | 24 | 348 | 4150 | 0.8 | 20.3 | 3.5 | 4660 | 165 |
| 100ZYT200-12v | 12 | 188 | 1500 | 1.2 | 24.5 | 3 | 1900 | 200 |
| 100ZYT200-24V | 24 | 188 | 1500 | 1.2 | 13 | 1.5 | 1900 | 200 |
