AC fans are available in ball bearing and sleeve bearing, wire type and terminal type. Some of these also available with plastic housing and metallic housing, as well as different impeller configurations.to runs on 100~120VAC and 220~240VAC.
| Model | Frame Size | Rated Voltage (VAC) |
Airflow *1 (CFM) |
|---|---|---|---|
| RA_8025 | 80 x 80 x 25 mm(3.15 x 3.15 x 0.98 in ) | 115, 230 | 19 |
| RA_8038 | 80 x 80 x 38 mm (3.15 x 3.15 x 1.50 in ) | 115, 230 | 26 – 29 |
| RA_9238 | 92 x 92 x 38 mm (3.62 x 3.62 x 1.50 in ) | 115, 230 | 41 – 46 |
| RA_1225 | 120 x 120 x 25 mm ( 4.69 x 4.69 x 0.98 in ) | 115, 230 | 50 – 68 |
| RA_1238 | 120 x 120 x 38 mm ( 4.69 x 4.69 x 1.50 in ) | 115, 230 | 91 – 111 |
| RA_1751 | 172 x 150 x 51 mm ( 6.77 x 5.91 x 2.00 in ) | 115, 230 | 141 – 180 |
